QNAP TS-412 User Manual

For example, whe
n 5 hard drives installed are available on the NAS, the LCD panel shows:
C o n f i g . D i s k s ?
→ R A I D 5
Press the “Select” button to browse more options, for example, RAID 6.
Press the “Enter” button and the following message shows. Press the “Select” button to
select “Yes” to confirm.
C h o o s e R A I D 5 ?
→ Y e s N o
When RAID 1, RAID 5, or RAID 6 configuration is executed, the system will initialize the
hard drives, create the RAID device, format the RAID device, and mount it as a volume on
the NAS. The progress will be shown on the LCD panel. When it reaches 100%, the RAID
volume can be accessed. Users can create share folders and upload files to the folders on
the NAS. In the meantime, to make sure the stripes and blocks in all the RAID component
devices are ready, the NAS will execute RAID synchronization and the progress will be
shown on “Disk Management” > “Volume Management” page. The synchronization rate is
around 30–60 MB/s (vary by hard drive models, system resource usage, etc.).
Note: If a member drive of the RAID configuration was lost during the synchronization, the
RAID device will enter degraded mode. The volume data is still accessible. If a new
member drive is added, the NAS will start to rebuild. The status can be checked on the
“Volume Management” page.
44

QNAP TS-412 Specifications

General

RAID levels	0, 1, 5, 6, 10
Storage drive size	2.5/3.5 \
Storage drive capacity	- GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA, Serial ATA II
Total installed storage capacity	- TB
Maximum supported storage capacity	8 TB
Number of storage drives installed	-
Number of storage drives supported	4
Flash memory	16 MB
Internal memory	0.25 GB
Internal memory type	DDR2
Processor model	6281
Processor family	Marvell
Processor frequency	1.2 GHz
Number of processors installed	1
Fan	90 mm
Dimensions (WxDxH)	180 x 235 x 177 mm
Power requirements	100-240V
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000; Windows XP; Windows Vista (32/ 64 bit); Windows Windows 7 (32/ 64 bit); Windows Server 2003/2008; Mac OS X; Linux & Unix.
DHCP client	Yes
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	TCP/IP
Security algorithms	HTTPS, SSH, SSL/TLS
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
Chassis type	Tower
LED indicators	HDD, LAN, Power, Y
Number of fans	1 fan(s)
Power consumption (sleep)	11 W
Power consumption (typical)	26 W
Power supply unit (PSU) capacity	120 W
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Weight	3000 g
