QNAP TS-431+ User Manual

2
Thank you for choosing QNAP products! This user manual provides description of the
hardware of the Turbo NAS and relevant guideline of certain functions. Please read carefully
and strictly adhere to the instructions of the manual.
This user manual is applicable to the following Turbo NAS models:
HS-210, HS-251, HS-251+, TS-112P, TS-128, TS-131, TS-212P, TS-228, TS-231,
TS-231+, TS-251, TS-251+, TS-251C, TS-253A, TS-253 Pro, TS-431, TS-431+, TS-431U,
TS-451, TS-451+, TS-451S, TS-451U, TS-453A, TS-453 Pro, TS-453S Pro (formerly
SS-453 Pro), TS-453U, TS-453U-RP, TS-463U, TS-463U-RP, TVS-463, TS-470U-SP/RP,
TS-531P, TS-563, TS-651, TS-653A, TS-653 Pro, TVS-663, TS-851, TS-853A, TS-853 Pro,
TS-853S Pro (formerly SS-853 Pro),TS-853U, TS-853U-RP, TS-863U, TS-863U-RP,
TVS-863, TVS-863+, TS-870U-RP, TS-879 Pro, TS-879U-RP, TS-EC879U-RP, TS-1079 Pro,
TS-1253U, TS-1253U-RP, TS-1263U, TS-1263U-RP, TS-1270U-RP, TS-1279U-RP,
TS-EC1279U-RP, TS-1679U-RP, TS-EC1679U-RP, IS-453S, TS-453mini, TAS-168, TAS-268
NOTE
 The “Turbo NAS”& “Turbo vNAS” are hereafter referred to as “NAS”.
 The product you purchased may not support certain functions dedicated to specific
models.
 All features, functionality, and other product specifications are subject to change
without prior notice or obligation.
 Information presented is subject to change without notice.
 No part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, mechanical, electronic, photocopying,
recording, or otherwise, without prior written permission of QNAP Systems, Inc.
QNAP and the QNAP logo are registered trademarks of QNAP Systems, Inc. Other
products and company names mentioned herein may be the trademarks of their
respective companies.

QNAP TS-431+ Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	- GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	4
Processor cores	2
Processor model	Alpine AL-212
Processor family	Annapurna Labs
Processor frequency	1.4 GHz
Flash memory	512 MB
Internal memory	1 GB
Internal memory type	DDR3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	120 mm
Product color	White
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Housing material	-
Cable lock slot type	Kensington
Type	NAS
Noise level	17.5 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Number of users	4096 user(s)
Browser supported	Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Other operating systems supported	Android, iOS
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows Vista Enterprise, Windows XP Professional
Fan voltage	12 V
AC input voltage	100-240 V
Power supply location	External
Power consumption (sleep)	11.89 W
Power consumption (typical)	26.15 W
Number of power supply units	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC, CE, BSMI, VCCI, C-TICK
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	219 mm
Width	160 mm
Height	169 mm
Weight	3000 g
Package weight	4300 g
