QNAP TS-431+ User Manual

69
Chapter 9. Use the LCD Panel
This feature is only provided by the NAS models with LCD panels. Please visit
http://www.qnap.com for details.
The NAS provides a handy LCD panel for users to perform disk configuration and view the
system information.
When the NAS has started up, the server name and IP address will be shown.
N
A
S
5
F
4
D
E
3
1
6
9
.
2
5
4
.
1
0
0
.
1
0
0
For the first time installation, the LCD panel shows the number of hard drives detected and
the IP address. Configure the hard drives.
Number of hard
drives detected
Default disk
configuration
Available disk configuration options*
1
Single
Single
2
RAID 1
Single > JBOD >RAID 0 > RAID 1
3
RAID 5
Single > JBOD > RAID 0 > RAID 5
4 or above
RAID 5
Single >JBOD > RAID 0 > RAID 5
> RAID 6
*Press the “Select” button to choose the option, and press the “Enter” button to confirm.
For example, when 5 hard drives installed are available on the NAS, the LCD panel shows:
C
o
n
f
i
g
.
D
i
s
k
s
?
→
R
A
I
D
5
Press the “Select” button to browse more options, for example, RAID 6.
Press the “Enter” button and the following message shows. Press the “Select” button to
select “Yes” to confirm.
C
h
o
o
s
e
R
A
I
D
5
?
→
Y
e
s
N
o

QNAP TS-431+ Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	- GB
Supported file systems	ext3, ext4, FAT32, HFS+, NTFS
Storage drive interface	Serial ATA II, Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	4
Processor cores	2
Processor model	Alpine AL-212
Processor family	Annapurna Labs
Processor frequency	1.4 GHz
Flash memory	512 MB
Internal memory	1 GB
Internal memory type	DDR3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Chassis type	Tower
Cooling type	Active
Fan diameter	120 mm
Product color	White
LED indicators	HDD, LAN, Status, USB
Number of fans	1 fan(s)
Housing material	-
Cable lock slot type	Kensington
Type	NAS
Noise level	17.5 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Number of users	4096 user(s)
Browser supported	Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SSH, SSL/TLS
Operating system version	4.1
Operating system installed	QNAP Turbo System
Other operating systems supported	Android, iOS
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows Vista Enterprise, Windows XP Professional
Fan voltage	12 V
AC input voltage	100-240 V
Power supply location	External
Power consumption (sleep)	11.89 W
Power consumption (typical)	26.15 W
Number of power supply units	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	FCC, CE, BSMI, VCCI, C-TICK
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	219 mm
Width	160 mm
Height	169 mm
Weight	3000 g
Package weight	4300 g
