Password: Specify an administrator password with 1 to 64 characters. The password supports all
ASCII characters.
7. Click Next.
The Set the date and time screen appears.
8. Specify the time zone, date, and time.
Tip
QNAP recommends connecting to an NTP server to ensure that the NAS follows the
Coordinated Universal Time (UTC) standard.
9. Click Next.
The Configure the network settings screen appears.
10. Select Obtain an IP address automatically (DHCP).
11. Click Next.
The Cross-platform file transfer service screen appears.
12. Select the types of devices that you will use to access shared folders on the NAS.
13. Click Next.
The Select the disk configuration screen appears.
14. Select Configure disks later.
For details on configuring disks, see the Storage Manager section of the QTS User Guide.
15. Click Next.
The Enable multimedia functions screen appears.
16. Select No.
Enabling the multimedia functions allows you to install multimedia applications after configuring the
disks in Storage Manager.
For details on enabling multimedia functions on QTS, see the System Administration section of the
QTS User Guide.
17. Click Next.
The Summary screen appears.
18. Review the settings.
19. Click Apply.
A confirmation message appears.
Warning
Clicking Confirm deletes all data on the drive before installing QTS.
20. Click Confirm.
QTS is installed.
Installing QTS Using the Cloud Key
Warning
Installing QTS deletes all data on the drives. Back up your data before proceeding.
1. Power on the NAS.
TS-431X User Guide
Installation and Configuration 24

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-431X and is the answer not in the manual?

QNAP TS-431X Specifications

General IconGeneral
Flash memory512 MB
Memory slots1
Internal memory2 GB
Internal memory typeDDR3
Maximum RAM supported8 GB
RAID levels0, 1, 5, 6, 10, JBOD
Storage drive size- \
Hot-swap drive baysYes
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interface-
Storage drives installedNo
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported4
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Processor cores2
Processor modelAL212
Processor familyAnnapurna Labs
Processor frequency1.7 GHz
Processor architectureARM Cortex-A15
Ethernet LAN data rates10, 100, 1000, 10000 Mbit/s
Supported network protocolsCIFS/SMB, AFP v3.3, NFSv3, FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC, TCP/IP, IPv4 & IPv6
Ethernet LAN data rate supported (max)10000 Mbit/s
Fiber optic connectorSFP+
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Chassis typeTower
Cooling typeActive
Fan diameter120 mm
Product colorBlack
LED indicatorsHDD, LAN, Power, Status, USB
Number of fans1 fan(s)
Cable lock slot typeKensington
TypeNAS
Noise level19.5 dB
Device classSmall & Medium Business
Share folderCIFS/SMB
Backup featuresCloud, iSCSI LUN
Browser supportedInternet Explorer 10+, Firefox 8+, Safari 4+, Chrome
Security algorithms256-bit AES, HTTPS, SNMP, SSH, SSL/TLS
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Fan voltage12 V
Power supply locationExternal
Power consumption (typical)26.7 W
Power supply unit (PSU) capacity90 W
Cables includedAC, LAN (RJ-45)
Operating system version4.3
Operating system installedQNAP Turbo System
Mac operating systems supportedMac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Weight and Dimensions IconWeight and Dimensions
Depth219 mm
Width160 mm
Height169 mm
Weight3000 g
