QNAP TS-473 User Manual

Component TS-473 TS-673 TS-873
Drive compatibility • 3.5-inch SATA hard disk drives
• 2.5-inch SATA hard disk drives
• 2.5-inch SATA solid state drives
M.2 SSD type 2 x M.2 SSD SATA 6 Gbps
M.2 SSD form factor • 2260
• 2280
SSD cache acceleration
support
• Drive bays 1 to 4
• M.2 slots 1 to 2
• Optional: M.2 SSD
using QNAP QM2
PCIe expansion card
• Drive bays 1 to 6
• M.2 slots 1 to 2
• Optional: M.2 SSD
using QNAP QM2
PCIe expansion card
• Drive bays 1 to 8
• M.2 slots 1 to 2
• Optional: M.2 SSD
using QNAP QM2
PCIe expansion card
Hot-swappable Yes
Note
M.2 SSDs are not hot-swappable.
Network
Gigabit Ethernet ports 4 x RJ45
External I/O Ports & Expansion Slots
PCIe slots 2 x low-profile PCIe 3.0
x4
2 x full-height PCIe 3.0
x4
2 x full-height PCIe 3.0
x4
USB ports • Front: 1 x USB 3.0 Type-A
Note
You can use the One-Touch Copy button with this port.
• Rear: 3 x USB 3.0 Type-A
Audio • 2 x 3.5 mm dynamic microphone jacks
• 1 x 3.5 mm line-out jack
• 1 x speaker
Note
You cannot use the speakers and the line-out jack
simultaneously.
Interface
Buttons • Power
• USB One Touch Copy
• Reset
IR sensor 1
Note
The QNAP RM-IR004 remote control is an optional separate
purchase.
TS-x73 User Guide
Product Overview 5

QNAP TS-473 Specifications

General

RAID levels	0, 1, 5, 6, 10, JBOD
RAID support	Yes
Storage drive size	2.5/3.5 \
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drive interface	Serial ATA III
Storage drives installed	No
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	4
Cables included	AC, LAN (RJ-45)
Number of screws	14
Operating system version	4.3.4
Operating system installed	QNAP Turbo System
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Type	NAS
Noise level	21.7 dB
Device class	Home & Home Office
Share folder	CIFS/SMB
Backup features	Cloud, USB drive, iSCSI LUN
Browser supported	Internet Explorer 10, Firefox 8, Safari 4, Google Chrome
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH, SSL/TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	IFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC
Chassis type	Tower
Cooling type	Active
Fan diameter	120 mm
Product color	Black
Fan diameter 2	60 mm
Number of fans	2 fan(s)
Cable lock slot type	Kensington
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	Built-in
Power consumption (typical)	56.23 W
Number of power supply units	1
Power consumption (HDD standby)	33.24 W
Power supply unit (PSU) capacity	250 W
Processor model	RX-421ND
Processor family	AMD Embedded R-Series SoC
Processor frequency	2.1 GHz
Processor boost frequency	3.4 GHz
On-board graphics card model	Not available
Flash memory	512 MB
Memory slots	4 x SO-DIMM DDR4
Internal memory	4 GB
Internal memory type	DDR4
Maximum RAM supported	64 GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
PCI Express x4 (Gen 3.x) slots	2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	279.6 mm
Width	199.3 mm
Height	188.2 mm
Weight	4840 g
