No. Component No. Component
2 3.5 mm speaker jack 7 Power input
3 Gigabit Ethernet RJ45 port 8 System fan
4 10GBASE-T RJ45 port 9 Speaker
5 USB 3.0 Type-A ports - -
Front Drive Numbering
Installation Requirements
Category Item
Environment • Room temperature: 0 to 40˚C (32 to 104˚F)
• Non-condensing relative humidity: 5 to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
• Flat, anti-static surface with no exposure to direct sunlight, liquids,
and chemicals
Hardware and peripherals • Storage drives
For details on compatible drives, go to https://www.qnap.com/
compatibility/.
• Network cable
Tools • Phillips #1 or #2 screwdriver
• Anti-static wrist strap
Setting Up the NAS
1. Place your NAS device in an environment that meets the requirements.
For details, see Installation Requirements.
2. Install the drives.
TS-963X User Guide
Product Overview 8
