TVS-x73e User Guide
Installation and Configuration 25
7.
Optional: Attach the QNAP bracket to the expansion card.
a.
Remove all screws of the existing bracket.
b.
Carefully pull the bracket away from the card.
c.
Attach the QNAP bracket to the card using the same screws.
d.
Verify that the bracket does not move.
8.
Install the expansion card.
a.
Hold the card by the edges.
b.
Insert the card into the slot.
c.
Attach the screw.
