QNAP TVS-872XT User Manual

2. Product Overview
This chapter provides basic information about the QNAP TVS-x72XT NAS.
About the TVS-x72XT
The TVS-x72XT is a high-performance NAS powered by an Intel® processor and supports up to 16 GB of
DDR4 memory. It features an HDMI port for external displays and a USB One Touch Copy port for quick and
convenient backup and data transfer. In addition to its three network ports (two 1GbE and one 10GbE), the
TVS-x72XT is equipped with two Thunderbolt™ 3 ports (through its PCIe 3.0 x16 slot) that provide a wide
range of possibilities, including extra data management capabilities and additional multimedia support.
Hardware Specifications
Warning
If your QNAP product has hardware defects, return the product to QNAP or a QNAP-
authorized service center for maintenance or replacement. Any attempt to repair or
perform maintenance procedures on the product by you or an unauthorized third-party
invalidates the warranty.
QNAP is not responsible for any damage or data loss caused by unauthorized
modifications and installation of unsupported third-party applications.
For details, see the QNAP Warranty Terms and Conditions.
Component TVS-472XT TVS-672XT TVS-872XT
Ordering Information
Ordering P/N TVS-472XT-PT-4G TVS-672XT-i3-8G TVS-872XT-i5-16G
Processor
CPU Intel® Pentium® G5400T Intel® Core™ i3-8100T Intel® Core™ i5-8400T
Frequency Dual-core 3.1 GHz 4-core 3.1 GHz 6-core 1.7 GHz base/3.3
GHz turbo
Architecture x86 64-bit
Encryption engine AES-NI
Graphics Embedded Intel® UHD
610 graphics processor
Embedded Intel® UHD 630 graphics processor
Memory
Pre-installed memory 4 GB RAM: 2 x 2 GB
SODIMM DDR4
8 GB RAM: 2 x 4 GB
SODIMM DDR4
16 GB RAM: 2 x 8 GB
SODIMM DDR4
Memory slots 2 x SODIMM DDR4
Important
• Use only QNAP memory modules to maintain system
performance and stability. For NAS devices with more
than one memory slot, use QNAP modules with identical
specifications.
• Using unsupported modules may degrade performance,
cause errors, or prevent the operating system from
starting.
Maximum memory 32 GB RAM: 2 x 16 GB
Flash memory 4 GB USB DOM
TVS-x72XT User Guide
Product Overview 4

QNAP TVS-872XT Specifications

General

RAID levels	0, 1, 5, 6, 10, 50, 60, JBOD
RAID support	Yes
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Number of M.2 (M & B) slots	2
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	8
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Processor family	Intel® Core™ i5
Processor frequency	- GHz
Processor manufacturer	Intel
On-board graphics card model	Intel® UHD Graphics 630
Flash memory	5000 MB
Internal memory	16 GB
Memory form factor	SO-DIMM
Internal memory type	DDR4
Maximum RAM supported	32 GB
Concurrent connections	3500
Ethernet LAN (RJ-45) ports	3
PCI Express x4 (Gen 3.x) slots	1
Chassis type	Tower
Cooling type	Active
Fan diameter	120 mm
Product color	Black
Fan diameter 2	60 mm
LED indicators	HDD, LAN, USB
Number of fans	4 fan(s)
Cable lock slot type	Kensington
Type	NAS
Noise level	24.2 dB
Device class	Small & Medium Business
Share folder	CIFS/SMB
Backup features	Cloud, iSCSI LUN
Browser supported	Apple Safari, Google Chrome, Microsoft Internet Explorer, Mozilla Firefox
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMPv3, SSH, SSL/TLS
Fan voltage	12 V
AC input voltage	100 - 240 V
Power supply location	Built-in
Power consumption (typical)	65.03 W
Power consumption (HDD standby)	41.47 W
Power supply unit (PSU) capacity	250 W
Operating system version	5.0.0
Operating system installed	QNAP QTS
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Linux operating systems supported	CentOS 7.0, SuSE Linux 12.0, SuSE Linux 12.3, SuSE Linux 15, Ubuntu 14.04, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04, Ubuntu 16.10, Ubuntu 17.10, Ubuntu 18.04 LTS, Ubuntu 20.04 LTS
Other operating systems supported	IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Ethernet LAN data rates	10, 100, 1000, 2500, 10000 Mbit/s
Supported network protocols	TCP/IP, IPv4, IPv6
Ethernet LAN data rate supported (max)	10000 Mbit/s
Cables included	AC, LAN (RJ-45)
Number of screws	48
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	279.6 mm
Width	329.3 mm
Height	188.2 mm
Weight	7060 g
Package weight	9190 g
