Installing Expansion Cards on the TVS-h674 and TVS-h874
The TVS-hx74 series supports selected expansion cards, some of which require QNAP PCIe brackets. QNAP-
branded expansion cards purchased from the company website are shipped with the brackets necessary to
t the TVS-hx74.
Warning
•
Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
Note
Check the expansion card power supply requirements and compatibility list before
installation. For more information, see www.qnap.com/compatibility.
1. Power o the device.
2. Disconnect the power cord from the electrical outlet.
3. Disconnect all cables and external attachments.
4. Remove the case cover.
a. Loosen the screws.
b. Slide the cover back.
c. Lift the cover o the device.
TVS-hx74 User Guide
Installation and Conguration 34
