IQ PANEL- HEADER/STATUS BAR
QOLSYS CONFIDENTIAL AND PROPRIETARY PAGE 5 OF 32
© Last updated 11/23/15 All rights reserved
STATUS TYPES & COLOR CODES
The green header is labeled “System Ready – Disarmed” and indicates that all of the
sensors are closed and the system is ready to be armed.
The yellow header is labeled “System Not Ready – Disarmed” and indicates that one or
more of the sensors are open. Touch this yellow bar to see a list of open sensors.
The orange header is labeled “System Armed- Stay Mode” and means that any entry
through a protected door or window will trigger the alarm. Note: When armed, the home
button and panic button will glow red.
The header bar is color coded based on system status, and shows the date, time, and
current status.
STATUS
BACKLIT BUTTONS
The panel’s “Panic” and “Home” buttons also
illuminate to show panel status.
Green LED when
Red LED when
During a power outage these LED lights will
NOT illuminate to save battery life if the panel is
running on battery only
CHECKING STATUS OUTSIDE THE HOME
You can also see the status of your home from your Alarm.com
mobile application, or from any web browser by logging into your
Alarm.com account.
If you want to know
whether your sensors are
open or closed, touch the
“Status” app on the
Home Screen
Go to your device and
search for “Alarm.com”
The red header is labeled “System Armed- Away Mode” and means that any entry
through a protected door or window or crossing the path of a motion detector will trigger
the alarm. Note: When armed, the home button and panic button will glow red.
