5 – AXP2O – Overview
Figure 16 – AXP2O Front Panel
The Axiom AXP2O provides analog audio output breakout,
power injection and control system connectivity to Attero Tech’s
Axiom endpoint products. The installer friendly form factor
allows it to be placed on an equipment rack shelf or mounted to
any flat surface.
Features:
o Analog Output - Two balanced line-level analog
outputs for connectivity to mixers, amplifiers and
signal processors.
o Axiom port - Supports connectivity to any Attero
Tech Axiom endpoint.
o RS-232 - Provides RS-232 connectivity to control
systems for extending control to supported Axiom
products (limited to one control enabled Axiom
endpoint on the Axiom bus)
o LED indication of power status
– AXP2O – What’s in the Box
The AXP2O comes supplied with the following:
o Axiom AXP2O device
o 24V AC/DC Power Supply
Figure 17 - Product Overview
