QSC ATTEROTECH Axiom Series - Device Specifications; ML1 Specs; USB1 Specs

Attero Tech by QSC Axiom Product Family
User Manual
 QSC, LLC 2020 614-00063
Device Specifications
ML1 Specs
Axiom
Physical Layer
Analog Audio, RS-232 Control, 24V DC Power
Connector (s)
8P8C
Cable Quality
CAT-5e or better, UTP
Power Specifications
DC Power
24V DC (via Axiom port)
Power Consumption
50mA @ 24V / 1.2W
Physical Dimensions
Width
1.66”
Height
1.14”
Depth
2.35”
Weight
0.35 lbs.
Regulatory Compliance
Certifications
WEEE
RoHS
REACH
Environmental Operating Specifications
Operating Temperature
0 to 40° C
USB1 Specs
Axiom
Physical Layer
Analog Audio, RS-232 Control, 24V DC Power
Connector (s)
8P8C
Cable Quality
CAT-5e or better, UTP
Power Specifications
DC Power
24V DC (via Axiom port)
Power Consumption
50mA @ 24V / 1.2W
Physical Dimensions
Width
1.66”
Height
1.14”
Depth
2.35”
Weight
Regulatory Compliance
Certifications
WEEE
RoHS
REACH
Environmental Operating Specifications
Operating Temperature
0 to 40° C
Audio Inputs (Mic/Line)
Connector Type
XLR – ¼” Combo
Gain
0 to 50 dB
Input Impedance
>2kOhms at any gain (mic) >10kOhms Line
Maximum Input Levels
+20 dBu @ minimum gain (XLR)
+18 dBu @ minimum gain (1/4”)
THD+N
<0.05% @ 1 kHz, -3 dBFS input, 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB (1/4”), 50-20kHz +/- 1 dB (XLR)
Dynamic Range
>110 dB at minimum gain
EIN
-115 dBu
Audio Inputs (3.5 mm Line)
Connector Type
3.5mm TRS
Gain
0 to 20 dB
Input Impedance
>10K ohms at any gain
Maximum Input Levels
+12 dBu @ minimum gain
THD+N
<0.05% @ 1 kHz, -3 dBFS input. 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB
Dynamic Range
>110 dB at minimum gain
USB
Connector Type
USB Type B
USB Mini Type B (for configuration)
Audio Connectivity
USB Audio 1.1, Compatible with Windows 7 or newer,
and MacOS 10.7 or newer
Input Impedance
>2kOhms at any gain (mic) >10kOhms Line
Maximum Input Levels
+20 dBu @ minimum gain (XLR)
+18 dBu @ minimum gain (1/4”)
THD+N
<0.05% @ 1 kHz, -3 dBFS input, 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB (1/4”), 50-20kHz +/- 1 dB (XLR)
Dynamic Range
>110 dB at minimum gain
Audio Output (3.5 mm Line)
Connector Type
3.5mm TRS
Gain
0 to 20 dB
Input Impedance
>10K ohms at any gain
Maximum Input Levels
+12 dBu @ minimum gain
THD+N
<0.05% @ 1 kHz, -3 dBFS input. 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB
Dynamic Range
>110 dB at minimum gain
