Attero Tech by QSC Axiom Product Family
User Manual
QSC, LLC 2020 614-00063
2 ML1 Overview
Figure 2 ML1 Front Panel
The Axiom ML1 provides an installation friendly simple to operate
analog audio extension solution for analog mic and line level
sources in cost-sensitive applications such as small and medium
sized retail, restaurant, education, and hospitality venues.
ML1 What’s in the Box
The ML1 comes supplied with the following:
o Axiom ML1device
o Includes interchangeable white and black Decora-style
inserts
o (1) White US Single Gang Decora® cover plate w/screws
o (1) Black US Single Gang Decora® cover plate w/screws
o (2) Wall plate mounting screws
Figure 3 - Product Overview
ID
Description
1
Gain Adjust Knobs
2
Signal Presence Indicators
3
3.5mm Input
4
XLR/TRS Input (1/4” TRS Padded for +20dBu support)
5
Axiom Port A Configuration Switches
6
Axiom Ports (A & B)
