Attero Tech by QSC Axiom Product Family
User Manual
QSC, LLC 2020 614-00063
BT1 Specs
Axiom
Physical Layer
Analog Audio, RS-232 Control, 24V DC Power
Connector (s)
8P8C
Cable Quality
CAT-5e or better, UTP
Power Specifications
DC Power
24V DC (center positive barrel jack)
Power Consumption
50mA @ 24V / 1.2W
Physical Dimensions
Width
1.66”
Height
1.14”
Depth
2.35”
Weight
Regulatory Compliance
Certifications
WEEE
RoHS
REACH
Environmental Operating Specifications
Operating Temperature
0 to 40° C
AXP2O Specs
Axiom Port
Physical Layer
Analog Audio, RS-232 Control, 24V DC Power
Connector (s)
8P8C
Cable Quality
CAT-5e or better, UTP
Power Specifications
DC Power
24V DC (center positive barrel jack)
Power Consumption
<30mA @ 24V / 0.72 W
Physical Dimensions
Width
5.6”
Height
4.2”
Depth
1.66
Weight
0.15 lbs.
Regulatory Compliance
Certifications
WEEE
RoHS
REACH
Environmental Operating Specifications
Operating Temperature
0 to 40° C
Audio Inputs (Bluetooth/Line)
Input Types
Stero Bluetooth® v3.0 audio receiver
Stereo Unbalanced Inputs on 3.5mm TRRS
Bluetooth Range
10m (30ft) minimum
Input Impedance
>10k Ohms Line (3.5mm)
Maximum Input Levels
+20 dBu @ minimum gain (XLR)
+18 dBu @ minimum gain (1/4”)
THD+N
<0.05% @ 1 kHz, -3 dBFS input, 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB (1/4”), 50-20kHz +/- 1 dB (XLR)
Dynamic Range
90 dB at minimum gain
Audio Outputs (Bluetooth/Line)
Output Types
Stero Bluetooth® v3.0 audio transmitter
Mono line level on 3.5mm TRRS
Output Impedance
<200 ohms on 3.5mm
Frequency Response
20-20 kHz, +/- 1 dB
Bluetooth® Profiles
A2DP
Media Audio Bridging (100-150ms latency)
HFP
Hands-Free Call Bridging (30ms latency)
AVRCP
A/V Remote Control
Audio Outputs
Connector Type
3.81mm, 3 position de-pluggable terminal blocks
Input Impedance
>2kOhms at any gain (mic) >10kOhms Line
Maximum Output Levels
+20 dBu
THD+N
<0.05% @ 1 kHz, -3 dBFS input, 20-20kHz
Frequency Response
20-20 kHz, +/- 1 dB
Dynamic Range
>100 dB
Control Port
Connector Type
3.81mm, 3 position de-pluggable terminal blocks
Physical Layer
RS-232
