66
QSC Audio Products, LLC
Part Number Description Qty. Reference Comment
CH-000885-00 PANEL, INPUT, BOP-2CH, KSUB, 1
CH-001025-00 SHIELD, LINE FILTER, SHORT, KW SERIES, 1
CO-000386-00 JACK, IEC, 3 POS, FEMALE, LOCKING 1
LB-001062-00 LABEL, RCM LOGO, REGULATORY CERTIFICATION MARK, , (AUSTRALIA & NEW
ZEALAND)
1
NW-000034-00 WSHR, SPLKG, , M3, 3.4 ID, 6.2 OD, 0.7 THK, STL, CLR, ZINC CR3, 4
NW-000140-00 NUT, HEX KEPS W/TOOTH WSHR, M4, , STL, CLR, ZINC, 1
NW-000147-00 NUT, HEX, M3, , STL, CLR, ZINC CR3, 4
NW-000173-00 WSHR, FLT, M3, , 3.2 ID, 8.0 OD, 1.0 THK, STL, BLK, ZINC CR3, 8
PL-000627-00 SPRINGSEAT, TRANSISTOR, BOP, NYLON, , 2
PL-000836-00 KNOB, , HOUSE OF K, PLASTIC, BLACK, 1
PL-000845-00 INSULATOR, TRANSISTOR, 1.525" X .950", SIL-PAD, , 4
SC-000205-00 SCR, PHH, PNH SERR BSE, PLASTITE, TAPPING, , , M4X1.75, 10 L, STL, BLK,
ZINC CR3, WAXED,
12
SC-000229-00 SCR, PHH, PNH, MACH, , , , M3, 8 L, STL, BLK, PHOS W/6219, 4
SC-000230-00 SCR, PHH, FLH, TPG, TYPE AB, , , #4-24, 3/8 L, STL, BLK, ZINC CR3, 2
SC-000240-00 SCR, PHH, PNH, MACH, , , , M3.5X0.6, 20 L, STL, NI-HARDENED, , 450 - 550-HV
HARDNESS
2
SC-000241-00 SCR, PHH, PNH, MACH, , , , M3.5, 8 L, STL, NI, HARDENED, , 450 - 550-HV
HARDNESS
14
SC-043051-PP PHILLIPS, PANHEAD, #4-20, 0.313" L, BLACK, STEEL "PLASTITE" 8
SW-000016-SW AC SWITCH, SPST, 20A, 125VAC, 1
WC-000466-00 CABLE ASSY, AC, 16 AWG, 3 CONDUCTOR, BOP-2CH, 5.50" L, 1
WC-000467-00 WIRE ASSY, AC SWITCH, 16 AWG, 1 CONDUCTOR, BOP-2CH, 5.00" L, BROWN 1
WP-000367-00 FAN ASSY, , BOP-2CH, , 1
WP-003314-00 PCB ASSY, , KSUB, , UNIVERSAL SUPPLY 1
14.12 WP-003314-00, KSub BOP PCB assembly
Part Number Description Qty. Reference Comment
CA-010002-30 10PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 2 C10, C11
CA-018002-30 18PF, 5 PCNT, 50V, CERAMIC NPO, SMT, 2 C59, C61
CA-110001-10 100PF, 5 PCNT, 500V, MICA, DIPPED, 2 C126, C127
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 4 C75, C76, C77, C78
CA-112001-30 120PF, 5 PCNT, 200V, CERAMIC NP0, 0805, 12 C1, C19, C20, C22, C28, C29, C30,
C31, C58, C60, C8, C9
CA-122002-30 220PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 7 C117, C49, C51, C93, C94, C95, C96
CA-122011-00 220PF, 10 PCNT, 250VAC, CERAMIC, DISC, Y1CAP 1 C52
CA-168003-30 680PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 2 C72, C73
CA-222001-00 0.0022UF, 20 PCNT, 250VAC, CERAMIC Y5U, DISC, YCAP 3 C104, C105, C124
CA-233003-30 0.0033UF, 10 PCNT, 50V, CERAMIC X7R, 0805, 2 C122, C50
CA-239002-30 0.0039UF, 5 PCNT, 50V, CERAMIC C0G/NP0, 0805, 2 C6, C7
CA-322013-30 0.022UF, 10 PCNT, 500V, CERAMIC X7R, 1206, 6 C111, C114, C123, C130, C132, C57
CA-347008-10 0.047UF, 10 PCNT, 250V, FILM, BOX, 5 C2, C32, C36, C46, C89
CA-368007-30 0.068UF, 10 PCNT, 100V, CERAMIC X7R, 0805, 1 C55
CA-410001-00 0.1UF, 20 PCNT, 250VAC, FILM, BOX STYLE, X2CAP 1 C108
CA-410012-30 0.1UF, 10 PCNT, 25V, CERAMIC X7R, 0805, 32 C100, C106, C107, C118, C12, C120,
C121, C138, C21, C26, C27, C3, C33,
C39, C41, C47, C5, C63, C64, C68,
C69, C70, C71, C74, C82, C83, C84,
C85, C86, C90, C91, C92
