3
Bridged (A+B) and Separate (C D ) Channels
Parallel Channels (ABCD)
PLD Amplifi er Signal Flow
— Figure 7 —
8.0
1250
1250
A+B
8.0
625
625
C
8.0
625
625
D
For A+B (Bridged)
Use two 2-wire cables connect to:
• 1+/1- for CH C on connector #3
•1+/1- for CH D on connector #4
For C & D (Separate)
Bi-amp operation, use one 4-wire cable connect to:
• 1+/1- for CH C on connector #3
• 2+/2- for CH D on connector #3
8.0
1250
1250
A+B
8.0
1250
1250
C+D
Use one 2-wire cable connect to:
• 1+/1- on connector #5
1
3
2
4
5
6
— Figure 8 —
A B C D
8.0
2500
2500
1
3
2
4
5
6
Use one 2-wire cable, connect to:
• 1+/1- on connector #1, #2, 3#, or #4
For One Loudspeaker
Full power to one loudspeaker
Use up to four 2-wire cables, connect to:
• 1+/1- on connectors #1 thru #4
For Multiple Loudspeakers
Full power for multiple loudspeakers in parallel
— Figure 9 —
Input Settings
Output Processing
1
2
3
4
RMS / Peak
Limiter
Amp Configuration
Delay
Delay
Delay
Delay
Mute
Mute
Mute
Mute
Source
Select
Source
Select
Source
Select
Source
Select
RMS / Peak
Limiter
RMS / Peak
Limiter
RMS / Peak
Limiter
Meter
Meter
Meter
Meter
Sensitivity
Switch
5-band
PEQ
5-band
PEQ
5-band
PEQ
5-band
PEQ
Gain
Gain
Gain
Gain
Button
Actuated
Crossover
Gain /
Polarity
Highpass
Filter
Lowpass
Filter
Gain /
Polarity
Highpass
Filter
Lowpass
Filter
Gain /
Polarity
Highpass
Filter
Lowpass
Filter
Gain /
Polarity
Highpass
Filter
Lowpass
Filter
Sensitivity
Switch
Sensitivity
Switch
Sensitivity
Switch
Meter
Meter
Meter
Meter
Set by Wizard
A
B
C
D
To Next Page
