QSC TouchMix-8 - FX Masters - Preset

47
TD-000472-00-B
FX Masters – Preset
Recall presets for the selected FX channel based on the current FX device. All Presets are available for all FX channels.
Home Select the FX
Masters Bank
Touch a
Select Button
Select
Presets Tab
Presets
FX Masters
FX 1
Refer to — Figure 36
1.
Presets Tab – Selects the Presets screen.
2. Current Preset Label – Displays the name of the currently active preset (if any).
3. Save / Save As Button – Displays a page with options for naming a scene and
selecting internal or USB storage destination.
4. External (USB) List – Displays a list of presets that have been saved on an External
(USB) drive.
5. Internal List – Displays a list of presets that have been stored to Internal mixer memory.
6. Factory List – Displays a list of the factory programmed presets available for the
currently loaded FX device. Touch a preset name to select.
7. Delete Button – Deletes a selected preset from Internal or External user memory.
8. Copy to USB Button – Copies the selected preset to an External (USB) Drive.
9. Copy to Internal Button – Copies the selected preset to the internal mixer memory.
10. Recall Preset Button – Recalls the effects parameters of a preset that has been selected
in the Factory, Internal or External (USB) window. Recall does not affect Aux Sends, EQ,
Mutes, or Group assignments
— Figure 43 —
1
3
6
10
7
2
4
5
8
9
