16.5 Multi-to-One VLAN Translation
Configuration
16.5.1 Introduction to Multi-to-One VLAN Translation
Multi-to-One VLAN translation, it translates the original VLAN ID into the new VLAN ID
according to user’s requirement on uplink traffic, and restores the original VLAN ID on
downlink traffic.
Application and configuration of Multi-to-One VLAN translation will be explained in detail in this
section.
16.5.2 Multi-to-One VLAN Translation Configuration
Multi-to-One VLAN translation configuration task list:
1. Configure Multi-to-One VLAN translation on the port
2. Show the related configuration of Multi-to-One VLAN translation
1. Configure Multi-to-One VLAN translation on the port
2. Show the related configuration of Multi-to-One VLAN translation
16.5.3 Typical application of Multi-to-One VLAN Translation
Scenario:
UserA, userB and userC belong to VLAN1, VLAN2, VLAN3 respectively. Before entering the
network layer, data traffic of userA, userB and userC is translated into VLAN 100 by
Command
Explanation
Port mode
vlan-translation n-to-1 <WORD> to
<new-vlan-id>
no vlan-translation n-to-1 <WORD>
Configure/delete Multi-to-One VLAN translation.
Command
Explanation
Admin mode
show vlan-translation n-to-1
Show the related configuration of Multi-to-One
VLAN translation.
