Chapter 49 VLAN-ACL Configuration
49.1 Introduction to VLAN-ACL
The user can configure ACL policy to VLAN to implement the accessing control of all ports in
VLAN, and VLAN-ACL enables the user to expediently manage the network. The user only
needs to configure ACL policy in VLAN, the corresponding ACL action can takes effect on all
member ports of VLAN, but it does not need to solely configure on each member port.
When VLAN ACL and Port ACL are configured at the same time, it will first match Port ACL
due to Port ACL priority is higher than VLAN-ACL.
VLAN-ACL ingress direction can implement the filtering of the packets, the packets match the
specific rules can be allowed or denied. ACL can support IP ACL, MAC ACL, MAC-IP ACL,
IPv6 ACL. Ingress direction of VLAN can bind four kinds of ACL at the same time.
49.2 VLAN-ACL Configuration Task
List
1. Configure VLAN-ACL of IP type
2. Configure VLAN-ACL of MAC type
3. Configure VLAN-ACL of MAC-IP
4. Configure VLAN-ACL of IPv6 type
5. Show configuration and statistic information of VLAN-ACL
6. Clear statistic information of VLAN-ACL
1. Configure VLAN-ACL of IP type
vacl ip access-group {<1-299> | WORD} {in |
out} [traffic-statistic] vlan WORD
no vacl ip access-group {<1-299> | WORD}
{in | out} vlan WORD
Configure or delete IP VLAN-ACL. (Egress
filtering is not supported by switch.)
2. Configure VLAN-ACL of MAC type
