QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
24
Function
Panel ID
Color
Status
LED Mode
Indicator
LED
Mode
Solid Green
Switching status
Solid Yellow
PoE status
10GE SFP+ Port
LED
25F to
28F
Off
No link is detected for this port.
Solid Green
The port has made a successful 1/10
Gbps link.
Blinking
Green
The port is sending and receiving
traffic at 1/10 Gbps.
10/100/1000
Base-T Ethernet
Port LED
1F to 24F
Off
No link is detected for this port.
Solid Green
The port has made a successful
10/100/1000 Mbps link.
Blinking
Green
The port is sending and receiving
traffic at 10/100/1000 Mbps.
PoE Status LED
1F to 24F
Off
PoE is disabled.
Solid Green
PoE is enabled.
PoE Status LED
1F to 24F
Blinking
Green (3 Hz)
PoE overload occurs.
1.4.6. LED Mode Button
The LED Mode button is used to switch the LED mode. The green LED Mode indicator indicates
the switching status. Press the LED Mode button, and the LED Mode indicator will turn yellow,
indicating the PoE status. Press the LED Mode button again, the indicator switches to indicating
the switching status.
If you want to switch the LED mode, press the button for over two seconds.
1.5. QSW-4700-52TX-POE
1.5.1. Specifications
Model
QSW-4700-52TX-POE
CPU
Dual-core CPU with the clock speed of 1.2 GHz
BOOTROM
16 MB
