QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
41
Item
Specification
Maximum Output
Current
12.5 A
Maximum Output
Power
150 W
Ground Leakage
Current
≤ 3.5 mA
Dimensions (W x
D x H)
196 mm x 50.5 mm x 40 mm (7.72 in. x 1.99 in. x 1.57 in.)
Weight
0.55 kg (1.21 lbs.)
Operating
Temperature
-10°C to 55°C (14°F to 131°F)
Storage
Temperature
-40°C to 70°C (-40°F to 158°F)
Relative
Operating
Humidity
5% to 95% RH (non-condensing)
Relative Storage
Humidity
5% to 95% RH (non-condensing)
Operating Height
0 to 5000 m (3.11 miles) above the sea level
1.8.1.2. Features
Features
Benefit
Conformal
Coating
Moisture-proof, salt spray-proof, mold-proof, insulation-proof and
leak-proof.
Protection
Undervoltage protection, output overcurrent protection, output
overvoltage protection and output short circuit protection.
I2C
Communication
The switch can communicate with the power supply module
through I2C.
Power
Redundancy
System supports 1+1 power redundancy. Dual power supply
modules are connected in parallel for current sharing.
Hot Swapping
In the power redundancy mode, the power supply module can be
replaced when the system is powered on.
Alarming
When a power fault occurs, the output status LED turns off.
