QSW-4700 Series Switches Hardware Installation and Reference Guide
Product Overview
42
1.8.1.3. LED
Function
Color
Status
Output Status
LED
Off
The power supply module is not
outputing power properly.
Solid Green
The power supply module is outputing
power normally.
1.8.2. QSW-M-4700-DC Module
The QSW-4700-28TX, QSW-4700-52TX, QSW-4700-28F and QSW-4700-52F switches support
the QSW-M-4700-DC power module. The QSW-M-4700-DC is a DC module (DC input and DC
output) providing an output voltage of 12 V and an output power of up to 150 W.
Note:
• The switch can be powered on by either one power supply module or dual power supply
modules. If both power supply modules are used, the switch works in the power
redundancy mode.
• At least one power supply module is required. If any slot is unoccupied, install a filler
panel to enable proper airflow.
1.8.2.1. Specifications
Item
Specification
Power Supply
Model
QSW-M-4700-DC
Switch Model
QSW-4700-28TX, QSW-4700-52TX, QSW-4700-28F, QSW-4700-
52F
Rated Input
Voltage Range
DC Input: -48 V DC to -60 V DC
Maximum Input
Voltage Range
DC Input: -36 V DC to -75 V DC
Maximum Input
Current
5 A
Output Voltage
12 V
Maximum Output
Current
12.5 A
Maximum Power
Output
150 W
Dimensions (W x
D x H)
196 mm x 50.5 mm x 40 mm (7.72 in. x 1.99 in. x 1.57 in.)
