Function
Panel ID
Color
Status
System Status LED
Status
Solid Red
1. The temperature at the air
intake and exhaust vents
exceeds the threshold greatly.
2. The system is not functioning
properly.
Power Supply Status
LED
PWR1/PW
R2
Off
The power supply module is not
seated.
Solid
Green
The power supply module is
seated and providing power to the
switch.
Solid
Yellow
The model of the power supply
module is not supported or cannot
be identified.
Solid Red
The redundant power supply
module is not functioning properly
or not connected with the AC
power cord.
Management Port
LED
MGMT
Off
No link is detected for this port.
Solid
Green
The port has made a successful
1000 Mbps link.
Blinking
Green
The port is sending and receiving
traffic at 1000 Mbps.
Solid
Yellow
The port has made a successful
10/100 Mbps link.
Management Port
LED
MGMT
Blinking
Yellow
The port is sending and receiving
traffic at 10/100 Mbps.
LED Mode Indicator
LED Mode
Solid
Green
Switching status
Solid
Yellow
PoE status
10GE SFP+ Port LED
49F to 52F
Off
No link is detected for this port.
Solid
Green
The port has made a successful
1/10 Gbps link.
Blinking
Green
The port is sending and receiving
traffic at 1/10 Gbps.
