178.854UK, 178.857UK User Manual
Internal media player
At the top of the rear panel is the media player section, which can provide playback of
recorded material internally or from external sources. Controls for this are shown below.
Select player mode between USB, SD, FM tuner or Bluetooth
For mp3 media, select between USB or SD/MMC memory device
Previous track / FM station
Next track / FM station
Repeat mode: single track or all tracks
Mute media player output
Play/Pause (scan in FM tuner mode)
By default, the media player starts up in “AUX” mode, which accepts a line input via the RCA
line input sockets (24) or 3.5mm jack input (11). Output level for the media player is governed
by the main VOLUME control (15) or muted by pressing the MUTE button.
Adjacent to the RCA line input is a twin RCA line output carrying the overall main mix for
connection onto further recording or PA equipment.
FM Tuner
Pressing the MODE button switches the media player to “FM tuner” mode. The display will
show the radio frequency that the media player is tuned to.
To tune the FM radio to available stations in the reception area, press and hold the
PLAY/PAUSE button for 3 seconds and the media player will scan all available stations and
store them as numbered presets. These can then be selected using the PREVIOUS and NEXT
buttons.
USB/SD player
Insert a USB memory stick or an SD/MMC card with mp3 or wma media stored on it into the
USB port or SD card slot and the media player can enter another mode. Pressing the MODE
button will now toggle between AUX, FM tuner and USB/SD playback.
Files on the USB or SD device must be mp3 or wma format for the media player to read them.
PLAY/PAUSE, PREVIOUS and NEXT buttons control playback and track navigation.
If both USB and SD/MMC media are connected, the USB/SD button will toggle between these.
Pressing the REPEAT button will toggle between 2 repeat play modes.
“RPT ONE” repeats the current track and “RPT ALL” repeats all tracks in the current folder.
