Technical Specifications
General
• Width: 18HP
• Depth: 22mm
• Power Consumption: +12V=175mA, -12V=8mA, +5V=0mA
Audio
• Sample Rate: 48kHz
• Bit-depth: 32 bit (internal processing), 24-bit (hardware conversion)
• True Stereo Audio IO
• High fidelity Burr-Brown converters
• Based on Daisy audio platform
Controls
• Knobs
∘ Resolution: 16-Bit (65,536 distinct values)
• CV Inputs
∘ Resolution: 16-Bit (65,536 distinct values)
USB Port
∘ Type: A
∘ External Power Draw: up to 500mA (for powering external devices via USB). Please note that addition-
al power drawn from the USB must be considered within your PSU’s total current consumption.
Noise Performance
• Noise Floor: -94dB
• Graph:
