39Quadra-Fire • Expression 36 (QV36A-FB) • 2062-900 Rev. S • 11/11
LOG #3: (SRV2062-703)
Place log #3 on the burner in the same way but
on the left front of the burner.
LOG #2: (SRV2062-702)
Place log #2 on the burner so that the bottom of
the log conforms with the contour of the burner.
The outside of the log should rest on the grate. The
front of the log will rest against the right andiron.
LOG #1: (SRV2062-701)
Place log #1 on the back of burner. Rest log on
back of the grate. The notches located on the bot-
tom of the log should rest over the back corners
of burner.
Figure 12.4
Figure 12.5
Figure 12.6
1
1
1
1
2
2
2
2
1
1
3
3
