Quadra-Fire • QFI30FB, QFI35FB • 2221-900 Rev. K • 3/11 16
A. Typical Appliance System
NOTICE: Illustrations and photos refl ect typical installations and are for design purposes only. Illustrations/diagrams are not
drawn to scale. Actual product may vary from pictures in manual
VERTICAL TERMINATION CAP
(SECTION 8.E)
VENT PIPE
(SECTION 8)
GAS LINE (SECTION 9)
ACCESS THROUGH EXISTING
MASONRY OR WOODBURNING
FIREPLACE
HEARTH
EXTENSION
SURROUND OR FRONT NOT SHOWN
SECTION 2.D AND SECTION 8.
MANTEL AND MANTEL LEG
SECTION 5.B AND 11.A
3 INCH FLEX LINERS
(SECTION 8)
Figure 4.1 Typical System
4
Getting Started
