Quadra-Fire TREKKER INSERT series User Manual

3January 8, 2019 7082-154E
TREKKER INSERT
A. Sample of Serial Number / Safety Label ......... 2
B. Warranty Policy ............................ 4
C. Quick Start Guide .......................... 7
1 Listing and Code Approvals ..............8
A. Appliance Certication....................... 8
B. BTU & E󰀩ciency Specications ............... 8
C. Glass Specications ........................ 9
D. Electrical Rating ........................... 9
E. Mobile Home Approved ...................... 9
F. Sleeping Room ............................ 9
G. California - Prop65 ......................... 9
2 Operating Instructions .....................10
A. Fire Safety ............................... 10
B. Non-Combustible Materials .................. 10
C. Combustible Materials...................... 10
D. Fuel Material and Fuel Storage...............10
E. Before Your First Fire ...................... 11
F. Filling the Hopper.......................... 11
G. User Interface ........................... 11
H. Startup.................................. 11
I. Fire pot Purge ............................ 11
J. Shutdown ................................ 11
K. Fire Characteristics ....................... 11
L. Your Pellet Appliance’s General Operating Parts . 12
M. Restarting the Appliance.................... 12
N. Clear Space ............................. 12
O. Tuning .................................. 12
P. Frequently Asked Questions ................. 13
3 Maintenance and Service .................14
A. Proper Shutdown Procedure ................. 14
B. Quick Reference Maintenance Chart .......... 14
C. General Maintenance and Cleaning ........... 15
D. Soot or Creosote Fire Awareness ............. 18
E. High Ash Fuel Content Maintenance........... 19
F. Ba󰀪e Removal............................ 19
G. Glass Replacement........................ 19
H. Convection Blower Replacement ............. 20
I. Combustion/Exhaust Blower Replacement ...... 20
4 Troubleshooting Guide .....................21
5 Reference Materials ..........................25
A. Component Functions ...................... 25
B. Service and Maintenance Log ............... 26
C. Exploded Drawings ........................ 29
D. Parts List ................................ 30
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Quadra-Fire is a registered trademark of Hearth & Home Technologies.

Quadra-Fire TREKKER INSERT series Specifications

General

Brand	Quadra-Fire
Model	TREKKER INSERT series
Category	Pellet stove
Language	English
