D. Parts List
Service Parts
R
TREKKER INSERT
Beginning Manufacturing Date: June 2018
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION
. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers
. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Hopper Lid
Matte Black 7036-107MBK
Porcelain Mahogany
7036-107PMH
Sienna Bronze 7036-107CSB
Gasket, Extruded - Field Cut to Size 10 FT 7000-320/10
2 Top Hinge Assembly SRV7036-006
3 Top
Matte Black 7036-101MBK
Porcelain Mahogany
7036-101PMH
Sienna Bronze 7036-101CSB
4 Catch Clip 7036-146
5 Elbow Catch 7000-393
6 Bracket, Catch 7036-145
7 Backer, Side Window 414-0280
8 Side
Matte Black 7036-103MBK
Porcelain Mahogany
7036-103PMH
Sienna Bronze 7036-103CSB
9 Gasket, Door Rope SRV7034-177 Y
10 Hinge Male SRV7034-138
11 Baf e SRV7034-263 Y
12 Latch, Baf e SRV7034-149
13 Hinge Pin Retainer 7036-112
14 Front Upper
Matte Black 7082-105MBK
Porcelain Mahogany
7082-105PMH
Sienna Bronze 7082-105CSB
15 Front Lower
Matte Black 7082-107MBK
Porcelain Mahogany
7082-107PMH
Sienna Bronze 7082-107CSB
Additional service part numbers appear on following page.
