Service Parts
R
TREKKER INSERT
Beginning Manufacturing Date: June 2018
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION
. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers
. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
16 Door Assembly SRV7080-015
16.1 Glass Retainer 7034-136
16.2 Glass Assembly 21” W x 14” H 7034-007 Y
16.3 Hinge, Female SRV450-2910
16.4 Door Latch Assembly 413-5200
Gasket, Channel 3 Mm X 32 - Field Cut to Size 10 Ft 7000-377/10 Y
17 Ash Pan Door SRV7034-133
18 Ash Pan Assembly SRV7034-069
Twin Ball catch SRV7000-532 Y
19 Intake Shield 7034-224 Y
20 Firepot Riser Assembly SRV7080-082
20.1 Firepot Assembly SRV7080-083 Y
20.2 Gasket, Firepot SRV7034-190 Y
20.3 Spring Pkg of 4 7000-513/4 Y
20.4 Rail, Auto-Clean SRV7034-152 Y
20.5 Plow Weldment, Auto-Clean SRV7034-024 Y
20.6 Hitch Pin Clip 3/32 Pkg of 10 7000-374/10 Y
20.7 Firepot Bottom SRV7034-153 Y
20.8 Firepot Floor Lever Assemby SRV7080-018 Y
21
Gasket, Rope, Ash Door SRV7034-178
22
Bottom
Matte Black 7036-109MBK
Sienna Bronze 7036-109CSB
Porcelain Mahogany 7036-109PMH
Additional service part numbers appear on following page.
#16 Door Assembly #20 Firepot Riser Assembly
16.3
16.2
16.1
16.4
20.1
20.2
20.3
20.4
20.7
20.6
20.5
20.8
To Next Page
