Quanmax QBOX-200S Series User Manual

Chapter 3
29
QBOX-200S Series User’s Manual
Table 6 Advanced Menu – Super IO Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
Super IO Configuration
>Serial Port 1 Configuration
ÆÅSelect Screen
ĹĻ6HOHFW,WHP
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.16.1242. Copyright (C) 2013, American Megatrends, Inc.
Table 7 Advanced Menu – Super IO Configuration – Serial Port 1 Configuration
BIOS SETUP UTILITY
Main Advanced Boot Chipset Power Security Exit
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Serial Port 1 Type [RS232]
ÆÅ: Select Screen
ĹĻ: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save and Exit
ESC: Exit
Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
Serial Port Type
Options: RS232, RS422, RS485
