Page #16 background imageLoading...
Page #16 background image
Chapter 1
16
QBOX-2600 Users Manual
Product Specifications
Construction
Aluminum extrusion
System Board
Intel
®
Cedarview-D Atom D2550 (1M Cache,1.86 Ghz)
Intel
®
NM10 Express Chipset
Memory
1 x DDR3 800/1066 SO-DIMM up to 4 GB
Front IO Panel
1x Push button (w/LED) for power on/off
1x Phone Jack for Line-Out
1x Phone Jack for MIC-In
1x WiFi LED (Green)
1x HDD LED (Red)
4x USB2.0
1x eSATA/USB Combo connector
Rear IO Panel
1x DC JACK for power input
1x RJ-45, GbE port
1x DP
1x DB-15 VGA
1x HDMI
2x DB-9 (RS-232/422/485)
1x Digital I/O (optional)
1x Reset CMOS
Storage
1 x 2.5” SATA HDD
Expansion
1 x Mini PCI-Express Socket (for optional WiFi or 3G module)
1x SIM card slot (Optional for 3G)
Cooling
Fanless
OS Support Windows 7
Power Unit
Input: 100-240 VAC, 50-60 Hz
Output: 40W, +19VDC / 2.1A output
Temperature /
Humidity
Operating Temperature:
With Industrial SSD: -10 ~ 60° C (Ambient with air flow)
With 2.5" HDD: 0 ~ 40° C (Ambient with air flow)
Storage Temperature:
-20°C to 80°C, 0%-90%, non-condensing
Dimensions
183.86 x 55.98 x 109.5 mm (W x H x D)
Weight 1600 g
Mounting Desktop, VESA-mount , Din Rail mount
Certifications CE, FCC Class A
Table 1 QBOX-2600 Specification
