Quanmax QBOX-2600 User Manual

Chapter 3
35
QBOX-2600 User’s Manual
Table 10 Advanced Menu –DIO Configuration
BIOS SETUP UTILITY
Main Advanced Boot Security Save & Exit
DIO Configuration
  Select Screen
↑↓ Select Item
Enter: Select
+- Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC Exit
User Configuration [Disabled]
DI-1 1
DI-2 1
DI-3
1
DI-4
1
DO-1 1
DO-2 1
DO-3
1
DO-4
1
Version 2.14.1219. Copyright (C) 2011, American Megatrends, Inc.
User Configuration
Options: Disabled, Enabled
Enabled:
DO-1
Options: Output Low, Output High
DO-2
Options: Output Low, Output High
DO-3
Options: Output Low, Output High
DO-4
Options: Output Low, Output High
