Mounting your PC to a monitor
Secure the VESA mounting kit to your monitor with four screws.
Figure 10 VESA mounting (1)
NOTE
To fasten the metal shelf, your monitor must comply with VESA75 or
VESA100 standard.
Place the QBOX-2600 onto the monitor and secure it with the heat dissipating fins
properly on VESA mount kit as shown below.
Figure 11 VESA mounting (2)
