ABOUT THE SYSTEM SYSTEM FEATURES
1-3
Note:
Internal USB port is reserved for UDK USB drive installation only. Feature hot plug is not available on this
internal USB port.
Rear I/O
 (2) USB 3.0 ports
 (1) VGA port
 (1) RS232 serial port
 (1) GbE RJ45 management port
 (1) ID LED
 (1) MicroSD slot
TPM Yes (optional, SPI mode)
ACPI ACPI compliance, S0, S5 support
Power supply
 500W and 800W Titanium/Platinum redundant PSU, 100-240VAC 50/60Hz,
AC/HVDC support
 1100W redundant DC PSU: Acbel I/P: DC -39 - -72V, 37A max.
System rating
 100-120/200-240Vac, 50/60Hz, 6.5/3.3A or 240Vdc, 3A (Per PSU inlet) for
PSU:500W and 800W
 100-120/200-240Vac, 50/60Hz, 7.4/4A or 240Vdc, 3.7A (Per PSU inlet) for
PSU:800W
 -39V- -72Vdc, 28A max. (Per PSU inet)
Fan (8) dual rotor fans (15+1 redundant)
System management IPMI v2.0 Compliant, on board "KVM over IP" support
Operating environment
 Operating temperature: 5°C to 40°C (41°F to 104°F)
 Non-operating temperature: -40°C to 70°C (-40°F to 158°F)
 Operating relative humidity: 20% to 85%RH
 Non-operating relative humidity: 10% to 95%RH
Table 1.1: System Specifications (Continued)
SPECIFICATIONS DESCRIPTION
