ABOUT THE SERVER SYSTEM REAR FEATURES
1-14
Service Port
(LAN 3) LED
Link/Act Green
On LAN Link
Blinking LAN access (off when there is traffic)
OFF Disconnect
Speed Green ON Link speed is 10/100/1000Mbits/sec
Table 1-9: Rear side LED Function and Behavior (1G LAN) (Continued)
I
CON NAME COLOR CONDITION DESCRIPTION
Table 1-10: Rear side LED Function and Behavior (10G LAN)
I
CON NAME COLOR CONDITION DESCRIPTION
Identification LED Blue
ON Unit selected for identification
OFF No identification requested
LAN1 LED
(Right)
Link/Act Green
On LAN Link
Blinking
LAN access (off when there
is traffic)
OFF Disconnect
Speed
Blue ON Link speed is 10Gbits/sec
Amber ON Link speed is 1Gbits/sec
-- OFF
Link speed is 10/100Mbits/
sec
