QUANTA STRATOS S210 Series S210-X12RS User Manual

ABOUT THE SERVER SYSTEM REAR FEATURES
1-13
System I/O LED Description
Rear I/O LED Description
Table 1-9: Rear side LED Function and Behavior (1G LAN)
I
CON NAME COLOR CONDITION DESCRIPTION
Identification LED Blue
ON Unit selected for identification
OFF No identification requested
LAN1 LED (Right)
Link/Act Green
On LAN Link
Blinking LAN access (off when there is traffic)
OFF Disconnect
Speed
Green ON Link speed is 100Mbits/sec
Amber ON Link speed is 1000Mbits/sec
-- OFF OFF, link speed is 10Mbits/sec
LAN2 LED (Left)
Link/Act Green
On LAN Link
Blinking LAN access (off when there is traffic)
OFF Disconnect
Speed
Green ON Link speed is 100Mbits/sec
Amber ON Link speed is 1000Mbits/sec
-- OFF OFF, link speed is 10Mbits/sec
