FORM QTC3-EG6 (1118)
QUANTECH
27
1669 [65.7]
1097 [43.2]
035-24059-002 REV-E
POWER ENTRY
330.2 [13.00] WIDE X 177.8 [7.00] HIGH
(190mm x 120mm EUROPEAN BUILD)
CONTROL PANEL BOTTOM DETAIL
(28mm EUROPEAN BUILD)
21 [0.8]
1177 [46.4]
MOUNTING
HOLES TYP
269 [10.6]
36 [1.4]
WATER CONNECTIONS
MOUNTING
HOLES TYP
254 [10.0]
36 [1.4]
822 [32.4]
3” VICTAULIC
INLET
3” VICTAULIC
INLET
3” VICTAULIC
OUTLET
WATER CONNECTIONS
LD23532
1921 [75.6]
2547 [100.3]
2911 [114.6]
FRAME LENGTH
2994 [117.9]
495 [19.5]
1735 [68.3]
741 [29.2]
588 [23.2]
16mm [5/8”]
MOUNTING
HOLES TYP
1276 [50.2]
1085 [42.7]
686 [27.0]
(OPTIONAL HEAT
RECOVERY UNIT)
FRAME WIDTH
OVERALL WIDTH
2256 [88.8]
2242 [88.3]
141 [5.5] OR 226.9 [8.93]
DIMENTION VARIES BASED ON
CHILLER MODEL SELECTED
OVERALL HEIGHT
FRAME HEIGHT
2248 [88.5]
1595 [62.8] (60Hz)
(1497mm (50Hz) )
OPTIONAL
DISCONNECT SWITCH
(STANDARD ON CE)
2077 [81.8]
82 [3.2]
51.4 [2.02]
1117 [44.0]
(1298mm EUROPEAN BUILD)
QTC3070TSE, QTC3075TSE, QTC3085TSE
Unit Dimensions (Cont'd)
NOTE:
Placement on a level surface of free of obstructions (including snow, for winter operation) or air circulation ensures rated performance, reli-
able operation, and ease of maintenance. Site restrictions may compromise minimum clearances indicated below, resulting in unpredictable
airow patterns and possible diminished performance. The unit controls will optimize operation without nuisance high-pressure safety cut-
outs; however, the system designer must consider potential performance degradation. Access to the unit control center assumes the unit is
no higher than on spring isolators. Recommended minimum clearances: Side to wall – 6'; rear to wall – 6'; control panel to end wall – 4'0'';
top – no obstructions allowed; distance between adjacent units – 10'. No more than one adjacent wall may be higher than the unit.
