Quantum Data 701A User Manual

2
Model 700A, 701A Video Test Generators
Quick Start Guide
Contents
Getting Started.....................................................................................................................................................3
Computer Interfaces ..........................................................................................................................................4
User Interface ........................................................................................................................................................5
Selecting Formats ...............................................................................................................................................6
Selecting Images .................................................................................................................................................7
Gating Outputs ....................................................................................................................................................7
Setting Power Save Preferences ....................................................................................................................8
Calibrating Generator ........................................................................................................................................9
Adjusting Horizontal Scan Frequency ...................................................................................................... 11
Detecting Formats Supported by a Monitor .......................................................................................... 12
Using Test Sequences ..................................................................................................................................... 13
Testing Audio ..................................................................................................................................................... 15
Testing HDCP Interfaces ................................................................................................................................ 15
Generating Psuedo Random Noise ............................................................................................................ 16
Using Video Generator Manager ................................................................................................................ 17
Creating Video Formats .................................................................................................................................. 18
Modifying Test Sequence .............................................................................................................................. 19
Pattern Descriptions ........................................................................................................................................ 20
Updating Firmware .......................................................................................................................................... 24
Specications ..................................................................................................................................................... 25
Service and Support Contacts .................................................................................................................... 26
w ww . . co m
information@itm.com1.800.561.8187

Quantum Data 701A Specifications

Horizontal Timing

horizontal frequency	1 KHz to 250 KHz
total pixels	144 to 4096
active range	16 to 4096 pixels

Vertical Timing

vertical frequency	1 Hz to 650 Hz
active lines	1 to 4096
scan types	Progressive, 2:1 Interlace

Video Outputs

timing accuracy	2%
SDI/HD-SDI bit stream	1.485 Gb/s and 1.485/1.001 Gb/s
signal swing	800 mV

Audio Outputs

connector	3.5 mm stereo phone jack
left signal tone	1 KHz
right signal tone	2 KHz

Power

battery type	Six AA 1500 mA-H rated rechargeable NiMH batteries
battery use time	8 hours
AC input	100-240 VAC @ 47-63 Hz

Size and Weight

size	H 5.5 x W 8.25 x D 2 inches
metric size	H 140 x W 210 x D 51 mm
ship weight	4 lbs
