Quantum DXi4700

Chapter 6: Replication
Receive VTL
Quantum DXi4700 User’s Guide 156
Figure 100: Cartridge Based Page
Tasks
Use the Cartridge Based page to perform the following tasks:
l View partitions eligible to receive Cartridge Based data (see Partitions Eligible to Receive Cartridge
Based Data below)
l Configure a partition to receive Cartridge Based Replication data (see Configuring a Target Partition
for Cartridge Based Replication on the next page)
l View statistics for partitions configured for Cartridge Based Replication (see Unpack Queue on
page 158)
Partitions Eligible to Receive Cartridge Based Data
The Partitions Eligible to Receive Cartridge Based Data section displays information for all VTL
partitions on the DXi4700 that are eligible to receive Cartridge Based Replication data from a source
partition. To be eligible to receive Cartridge Based Replication data, a partition must have data deduplication
enabled at the time it is created.
The Partitions Eligible for Replication section displays the following information:
Partition Name The name of the partition.
State The state of Cartridge Based Replication for the partition (Enabled or Disabled).
Sync ID The Sync ID used to identify the source partition that will send replicated data to the partition.
Access The selected access option for the partition (Locked or Unlocked).
