Quantum DXi4700

Chapter 9: Configuration
VTL Configuration
Quantum DXi4700 User’s Guide 225
Target Port The Fibre Channel port (target) associated with the group.
Partition Name The VTL partition associated with the group.
Devices The number of virtual media changers (VMCs) and virtual tape drives (VTDs) associated
with the group
Note: Click a column heading to sort the rows in the table by that column. Click the column heading
again to reverse the sort order.
Adding a Remote Host Access Group
Add a host access group to associate a VTL partition with a host (a Fibre Channel initiator on the SAN) and
a target (a Fibre Channel port on the DXi4700).
To add a host access group:
1. Click Add.
The Map Remote Hosts, Define Groups page displays (see Figure 143 below).
Figure 143: Map Remote Hosts, Define Groups Page
2. Enter information about the host access group:
Group Name Enter a name for the group.
Partition Select the partition to associate with the group.
