Quantum DXi4700

Chapter 3: Remote Management
The Remote Management Console
Quantum DXi4700 User’s Guide 63
DXi4700 Model Number DXi4700 Configuration
DXi4700 - VTL 5–135 TB usable for data storage
3 x 1 GbE Ethernet ports
(Optional) 2 x 10 GbE Ethernet ports or 2 x 10 GBase-T Ethernet ports.
2 x 8 Gb Fibre Channel ports (for host or SAN connection)
DXi4700 - Multi-Protocol 5–135 TB usable for data storage
3 x 1 GbE Ethernet ports
(Optional) 2 x 10 GbE Ethernet ports or 2 x 10 GBase-T Ethernet ports.
2 x 8 Gb Fibre Channel ports (for host or SAN connection)
2 x 8 Gb Fibre Channel ports (for PTT)
Low Space Management
As disk capacity is used and free disk space approaches low levels, the DXi4700 automatically responds as
detailed in the table below.
When the DXi4700 enters the Low Space state, space reclamation and compaction are automatically
started to free up disk space (see Space Reclamation on page 346). Space reclamation and compaction
end when the DXi4700 exits the Low Space state.
When the DXi4700 enters the Critical Reserve Space state, backup ingest is stopped, and target
replication to the system is paused. Backup ingest and target replication resume when the DXi4700 exits the
Critical Reserve Space state.
Note: The system generates a service ticket and an admin alert when it enters the Low Space,
Critical Reserve Space, and No Space states. In addition, a service ticket and an admin alert are
generated when Used Disk Space reaches 85% and 95% of total disk capacity.
DXi4700 State Disk Space Level System Actions
Normal (Green) Normal disk space Low Capacity button is dark.
Backup ingest and replication occur
as normal.
Space reclamation occurs at
normally scheduled times.
Low Space
(Yellow)
Free Space is less than:
850 GB + 100 GB x (total usable capacity in TB / 10
TB)
Low Capacity button is lit.
Backup ingest and replication occur
as normal.
Space reclamation is automatically
started.
