Quantum QN-I-270 User Manual

16 | www.qntmnet.com
Router
 Select option Router and click “Proceed”.
 Configure WLAN (SSID) and Local subnet parameters and click “Proceed”.
Parameter
Value
WLAN
Country
Select country for radio management.
Timezone
Select timezone for RUDDER management.
WLAN Name
Define a name for the network.
SSID
Define visible wireless network name.
Password
Configure a passphrase for SSID.
Local Subnet
IP Address
LAN IP address. This IP address can be used for
accessing this Access Point.
Subnet Mask
LAN subnet mask.
 Review the Configuration Summary. Click “Reconfigure” if any changes are
required or click “Proceed” to complete the configuration.
Figure 18 Figure 19
