Attach QXS-412/424 Side Brackets
QX and QXS 12- and 24-Drive Rackmount Install Guide 5
The illustration below shows bracket alignment for a 24-drive chassis.
Figure 2: Attaching bracket to 24-drive chassis
1
1. Screw: Code A - P/N:01-00000142
