QXS-4 Series Specifications 15
Chapter 3
QXS-4 Series Specifications
This chapter provides the following information:
• QXS-412/424/448 RAID and Expansion Chassis
• QXS-456 RAID and Expansion Chassis
• QXS-4 Series RAID and Expansion Physical Requirements
• QXS-4 Series RAID and Expansion Rackmount Chassis Weights
QXS-412/424/448 RAID and Expansion Chassis
Table 1 0 identifies physical dimensions of the QXS-412/424/448 RAID and expansion chassis.
Ta ble 10 QXS-412/424/448 RAID and Expansion Chassis Physical Dimensions
Chassis Height Width
(chassis only)
Depth
(excluding cables)
Maximum # Drives
QXS-412 RAID 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
20.57 inches
(52.25cm)
12 (LFF: 3.5 inch)
QXS-412 Expansion 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
20.57 inches
(52.25cm)
12 (LFF: 3.5 inch)
QXS-424 RAID 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
20.46 inches
(51.9cm)
24 (SFF: 2.5 inch)
QXS-424 Expansion 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
20.46 inches
(51.9cm)
24 (SFF: 2.5 inch)
QXS-448 RAID 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
30.6 inches
(77.724cm)
48 (SFF: 2.5 inch)
QXS-448 Expansion 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
30.6 inches
(77.724cm)
48 (SFF: 2.5 inch)
