QXS-6 Series Specifications 29
Chapter 4
QXS-6 Series Specifications
This chapter provides the following information:
• QXS-648 RAID and Expansion Chassis
• QXS-656 RAID and Expansion Chassis
• QXS-6 Series RAID and Expansion Physical Requirements
• QXS-6 Series RAID and Expansion Rackmount Chassis Weights
QXS-648 RAID and Expansion Chassis
Table 1 8 identifies physical dimensions of the QXS-648 RAID and expansion chassis.
Packaged Dimensions and Weight
Table 1 9 identifies the packaged dimensions and weight of the QXS-648 RAID and expansion chassis.
Ta ble 18 QXS-648 RAID and Expansion Chassis Physical Dimensions
Chassis Height Width
(chassis only)
Depth
(excluding cables)
Maximum # Drives
QXS-648 RAID 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
30.6 inches
(77.72cm)
48 (2.5 inch)
QXS-648 Expansion 2U (3.5 inches/
8.89cm)
17.6 inches
(44.7cm)
30.6 inches
(77.72cm)
48 (2.5 inch)
Ta ble 19 QXS-648 RAID and Expansion Chassis Packaged Dimensions and Weight
Chassis Height Width Depth Weight
QXS-648 RAID
(FC/iSCSI)
9.75 inches/
24.77cm
24 inches/60.96cm 37.875 inches/
96.20cm
110 lbs/49.90kg
QXS-648 RAID (SAS) 10.125 inches/
25.72cm
23.75 inches/
60.33cm
37.25 inches/
94.62cm
90 lbs/40.82kg
QXS-648 Expansion 9.875 inches/
25.08cm
23.875 inches/
60.64cm
37.75 inches/
95.89cm
70 lbs/31.75kg
