Quantum QXS Series User Manual

Chapter 1: Components
QXS-3 Series Storage
QX and QXS Setup Guide 3
Figure3:2U12 Drive Chassis (Bezel Removed)
Left Ear Right Ear
32
1
1. ChassisIDLED
2. DrivestatusLED:Power/Activity
3. DrivestatusLED:Fault
4. 3.5"driveblank(typical12slots)
2U24-Drive Chassis
Figure4:2U24 Drive Chassis (Bezel Installed)
Figure5:2U Drive Chassis (Bezel Installed)
5
6
7
8
1
2
3
4
5
1. ChassisIDLED
2. ChassisStatusLED:UnitLocator
3. ChassisStatusLED:Fault/ServiceRequired
4. ChassisStatusLED:FRUOK
5. ChassisStatusLED:TemperatureFault
Note:LEDs for drive chassis are described in LEDs for 56-Drive RAID Chassis (4U56) on page 175.
