Quantum QXS Series User Manual

Chapter 1: Components
QXS-4 Series and StorNext Storage
QX and QXS Setup Guide 11
2U12-Drive Chassis
Figure13:2U Drive Chassis (Bezel Installed)
5
6
7
8
1
2
3
4
5
1. ChassisIDLED
2. ChassisStatusLED:UnitLocator
3. ChassisStatusLED:Fault/ServiceRequired
4. ChassisStatusLED:FRUOK
5. ChassisStatusLED:TemperatureFault
Figure14:2U12 Drive Chassis (Bezel Removed)
Left Ear Right Ear
32
1
1. ChassisIDLED
2. DriveStatusLED:Fault
3. DriveStatusLED:Power/Activity
NotShown-3.5"DriveBlank
