Chapter 6: LEDDescriptions
LEDs for 12-, 24-, 48-Drive Systems
QX and QXS Setup Guide 165
Drive LEDs
Figure117:3.5" LFF drive
2
1
Figure118:2.5" SFF drive
1
2
