Quantum Superloader 3 Manual

Quantum SuperLoader 3: Rackmount Replacement
6-68061-01 Rev A
December 2013
8 Removing the SuperLoader 3 from the Rackmount
WARNING: Injury may occur if the unit is not supported when you remove
the front screws. The screws are holding up the front of the unit.
4 While supporting the front of the SuperLoader 3, remove the four (4) front
screws (see Figure 4).
Figure 4 SuperLoader 3 Front
Screws and Support Brackets
SuperLoader 3
bracket
Support bracket
Front screws
5 Using two people, or an appropriately rated mechanical lift, remove the
SuperLoader 3 from the rack; complete the following steps:
a Have one person slide the SuperLoader 3 out of the rack while
supporting it from the bottom.
b The other person should handle the back of the unit and depress the
locking tab on the support bracket while sliding the unit forward.
